    Open Type Original Diesel Engine 160KW Generator Genset With 200KVA SDEC Diesel Generator

    Ask Lasest Price
    Brand Name : Ai Power
    Model Number : ASC220
    Certification : CE, ISO9001
    Payment Terms : L/C, T/T,
    Supply Ability : 200 units per month
    Delivery Time : 30 to 35 days
    • Product Details
    • Company Profile

    Open Type Original Diesel Engine 160KW Generator Genset With 200KVA SDEC Diesel Generator

    Open Type Original Diesel Engine 160KW Generator Genset With 200KVA SDEC Diesel Generator

    AI power SDEC series generator set adopts SDEC engine as the power source. Shanghai Diesel Engine Co., Ltd. (SDEC), with SAIC Motor Corporation Limited as its main shareholder, is a large state-owned high-tech enterprise engaged in research and development and manufacture of engines, engine parts, possessing a state-level technical center. Its former was Shanghai Diesel Engine Factory that was established in 1947 and was restructured into a stock-shared company in 1993 with shares of A and B.


    Open Type Original Diesel Engine 160KW Generator Genset With 200KVA SDEC Diesel Generator


    SDEC Engine Specifications:

    GENERAL ENGINE DATA
    Engine manufactureShanghai Diesel Engine Co., Ltd. (SDEC)
    Engine brandSDEC
    Engine model6HTAA6.5-G23
    Engine speed (rpm)1500
    Engine output(kWm)
    Standby Power204
    Prime Power185
    Engine Type4-Cycle, In-line, 6-Cylinder Diesel, water cooled, Turbo charged
    Bore x Stroke (mm)114*144
    Displacment (litre)8.82L
    Compression Ratio18:1
    FUEL SYSTEM
    Injection pumpLongkou in-line “P” type
    GovernorRSV
    Fuel Consumption (litre/hour)
    25% load13.4
    50% load22.8
    75% load32.8
    100% load44.1
    MECHANISM
    TypeOver head valve
    Number of valveIntake 2, exhaust 2 per cylinder
    Valve lashes at coldIntake 0.25mm, Exhaust 0.50mm
    ENGINEERING DATA
    Heat rejection to coolant18.6kcal/sec
    Heat rejection to intercooler11.6m3/min
    Exhaust system6 kPa max.
    Exhaust gas temp.600
    COOLING SYSTEM
    Cooling methodFresh water forced circulation
    Coolant capacity12L
    Water Temperature
    Maximum for standby and Prime (°C)100/104
    Before start of full load (°C)40
    Thermostat TypeWax–pellet type
    LUBRICATION SYSTEM
    Lub. MethodFully forced pressure feed type
    Oil pan capacityMax. 19 liters , Min. 15 liters
    Oil pumpGear type driven by crankshaft
    Oil filterFull flow, cartridge type
    Lub. OilRefer to Operation Manual
    ELECTRICAL SYSTE
    Battery Charging Alternator24V×55A alternator
    Starting motor24V×4.5kW
    Battery Voltage24V
    Battery Capacity120 Ah (recommended)

    Product Photos:

    Open Type Original Diesel Engine 160KW Generator Genset With 200KVA SDEC Diesel Generator


    Open Type Original Diesel Engine 160KW Generator Genset With 200KVA SDEC Diesel Generator


    Open Type Original Diesel Engine 160KW Generator Genset With 200KVA SDEC Diesel Generator


    Open Type.

    ● Famous brand engine couple with high quality alternator
    ● Large size cooling radiator
    ● Heavy duty steel base frame
    ● Strong anti-vibration mat
    ● Standard free maintenance battery
    ● AC alternator for battery charger
    ● Heavy-duty air filter, oil filter, water filter
    ● Famous brand controller and breaker
    ● Optional fuel tank, silent canopy, ATS, synchronization panels.


    FAQ

    1. What is your warranty period?
    A:Our warranty period is 1 year or 1000 running hours, whichever comes first (Except the damageable spare parts of genset caused by incorrect man-made operation).


    2. Does your generator have global warranty?
    A:Yes. Gensets powered by USA famous engine, with UK famous engine, Volvo, Iveco have the global warranty service. And the alternators Stamford, Leroysomer, Meccalte, Marathon also have the global warranty service.


    3. What is your payment terms?
    A:T/T 30% advance payment, the balance 70% shall be paid before shipment, L/C at sight.


    4. Can the generators be customized?
    A: Yes. Our generators can be customized depending on customer's detailed requirements. We can supply generators for rental business, home use, industrial projects, army projects, power station, etc. The generators we supply is suitable for indoor and outdoor use, lower and high temperature environment.


    5. Can you use our logo?
    A: Yes. For mass orders, we can use customer's logo instead of ours.
