Low Fuel Consumption Cummins Diesel Generator Set With Engine Model 6BT5.9-G2

Ask Lasest Price
Brand Name :	Ai Power 80KW 100KVA Cummins Diesel Power Prise
Model Number :	AC125
Certification :	CE, ISO9001
Price :	USD 8000 to 10000 Per Unit Negotiable
Payment Terms :	Western Union, L/C, T/T, MoneyGram
Supply Ability :	300 Sets Per Month
Delivery Time :	30 Days

Add to Cart

Product Details
Company Profile

Low Fuel Consumption Cummins Diesel Generator Set With Engine Model 6BT5.9-G2

Low Fuel Consumption 100 kva Cummins diesel generator diesel set 6BT5.9-G2 diesel cummins

Choose a Cummins engine. Cummins was founded in 1919 and is headquartered in Columbus, Indiana, USA. Cummins has more than 680 distributors in 137 countries and regions around the world, and more than 5,000 service outlets all over the world. As the largest foreign investor in China's engine industry, Cummins owns Chongqing Cummins Engine Co., Ltd. in China (producing M, N and K series diesel engines) and Dongfeng Cummins Engine Co., Ltd. (producing B, C and L series diesel engines) and other manufacturers, and produce them according to Cummins' global unified quality standards. Cummins' nationwide service network provides users with the fastest service guarantee.

We have power from 10kw-2000kw,any interesting please contact with us to quote the best price for you
GenSet Model	AC110	Rated Power (KW)	80
Engine Model	6BT5.9-G2	Rated Power (KVA)	100
Alternator Model	TAL-A44-D	Standby Power(KW)	88
Frequency (Hz)	50	Standby Power(KVA)	110
Phase	Three Phase	N.W (kg)	1800
Rated Current (A)	250	Size (LWH)mm	2900×1100×1800
Quantity/20FCL	4	Quantity/40HQ	5
Details of Engine
Brand/Original	Cummins	Type	4-Stroke,V In-line,Water Cool, Electric start
Engine Model	6BT5.9-G2	Cylinder No	4
Displacement ( L)	5.9	Bore and Stroke (mm)	105*125
Rated Power (KW)	66	Volume of Oil (L)	15
Rated Power (KVA)	82.5	Combustion	Direct injection
Fuel Consumption(g/kw.h)	214	Aspiration Type	Turbocharged
Governor	Electrical Governor	Radiator Water Tank	50℃
Details of Alternator
Type	AI Power	Efficient	92%
Alternator Model	EM-224E	A.V.R	R150
Type	Brushless sel-excited	Protection	IP23
Prime Power (KW)	80	Insulation	Class H
Winding Lead	12	Factor	0.8
Control Panel
Brand/Original	Deepsea	Model	6120/7320

1. Performance of Cummins diesel generator set
(1) Group technical performance
Cummins diesel generator set phase direction: A(U) B(V) C(W)
Stator: Oblique slot structure, 2/3 of the winding, will effectively suppress the waveform distortion of the neutral current and output voltage.
Rotor: Dynamically balanced before assembly and directly connected to the engine through a flexible drive disc. Well-developed damper windings reduce oscillations when paralleled.
Cooling: Direct drive Cummins diesel generator set centrifugal fan.

Low Fuel Consumption Cummins Diesel Generator Set With Engine Model 6BT5.9-G2

Basic characteristics of Cummins diesel generator set
The low reactance design of the generator makes the waveform distortion under the non-linear load extremely small, and has a good starting performance with a motor
Compliant with standards: ISO8528, ISO3046, BS5514, GB/T2820-97
Common power: refers to the continuous operating power under variable load conditions, allowing 10% overload for 1 hour every 12 hours
Standby power: refers to the continuous operating power under changing load conditions in emergency state
Standard voltage is 380VAC-440VAC, all rated power is 40℃ ambient power
