Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW

    Buy cheap Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW from wholesalers

    Buy cheap Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW from wholesalers
    • Buy cheap Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW from wholesalers
    • Buy cheap Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW from wholesalers
    • Buy cheap Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW from wholesalers

    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW

    Ask Lasest Price
    Brand Name : Ai Power
    Model Number : AP550
    Certification : CE, ISO9001
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 200 units per month
    Delivery Time : 30 to 35 days
    • Product Details
    • Company Profile

    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW


    Electricity Generation Alternative Energy 500KVA Generator Silent 400KW Perkins Diesel Generator Set For Sale

    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW


    Product characteristics:

    1. Our cooperate with famous diesel engine -Powered by famous Perkins engines.
    2. Equipped with famous Brushless alternator - Optional Stamford, Leroy Somer, Marathon, Meccalte.
    3. Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working
    4. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen, ComAp,
    5. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
    6. Generator equipped with 24V DC battery with charger, battery connects wire.
    7. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.
    8. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance



    Generator Specifications:


    GENERAL ENGINE DATA
    Engine manufacturePerkins Engines Company Limited
    Engine brandPerkins
    Engine model2506C-E15TAG2
    Engine speed (rpm)1500
    Prime powerStandby power
    Gross engine power (kWb)451495
    Typical Genset electrical output 0.8pf 25ºC (100 kPa) (KW)400440
    Cylinders6-cylinder, vertical in line
    Cycle4 stroke, comression ignition
    Induction systemTurbocharged, air to air charge cooling
    ICombustion systemDirecct injection
    Compression ratio16:1
    Bore * Stroke (mm)137*171
    Cubic capacity (Litre)15
    FUEL SYSTEM
    Injection systemMEUI
    Governor typeelectronic
    Fuel Consumption (litre/hour)
    Standby114
    Prime+10%114
    Prime106
    75% output power81
    50% output power55
    COOLING SYSTEM
    Max. top tank temperature (°C)107
    Thermostat operating range (°C)88-98
    LUBRICATION SYSTEM
    Total system capacity (liter)62
    Maximum sump capacity (liter)53
    Minimum sump capacity (liter)45
    Oil temperature at normal operating conditions (°C)95
    Oil temp. Max. continuous operation (°C)114
    Oil pressure at rated speed (kPa)420
    Oil pressure Minimum @80°C (kPa)200
    INDUCTION SYSTEM
    Maximum air intake restriction of engine (kPa)
    Clean filter3.7
    Dirty filter6.2
    Combustion air flow(standby/prime power) (m3/min)35.8 / 36.6
    EXHAUST SYSTEM
    Back pressure for total system (kPa)6.8
    Exhaust gas temp. after turbo(standby/prime power)(°C)550 / N/A
    Exhaust gas flow (standby/prime power) (m3/min)94 / 98
    ELECTRICAL SYSTEM
    Alternator voltage (volts)24
    Alternator output (amps)70
    Stater motor type (volts)24
    Starter motor power (kw)

    7.5


    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW


    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW

    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW


    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW


    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW


    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW


    Electricity Generation Alternative Energy Perkins Diesel Generator Set 500KVA 400KW


    Detection and protection function

    • Over / under speed, Low Oil Pressure, High Water Temperature, under Battery Volt, Low water level,Three failed to start alarm

    • Over / under voltage,Over current,Over / under frequency, Over Power, Short circuit

    Optional features

    • RS485 (DSE7320)RS485(DSE7320)

    • Fuel level display and low-alarm

    • Water level low-alarm

    • Water Pre- heating in low temperature

    • ATS

    • Automatic parallel (DSE6120 / DSE7320)

    • Other self-definition functions

    • big power 1mva silenced diesel generator set price


    FAQ

    1. What is your warranty period?

    A: It’s 1 year or 1000 running hours whichever comes first. But based on some special project, we can extend our warranty period.

    2. Can you accept OEM?

    A. Yes, we can accept OEM.

    3. What’s your payment term?

    A: We can accept T/T 30% in advance and the balance 70% shall be paid before shipment or LC at sight.

    4. What’s your delivery time?

    A:Our normal delivery time is 2 to 4 weeks. But if your order is some special engine and alternator, the delivery time will be longer.
