Heavy Duty Engine 600KW Diesel Generator 750KVA Power Generator
With Perkins Alternator
AI power UK Perkins series generator set adopts UK Perkins engine
as the power source. It’s one of the world’s leading diesel engine
manufacturers since 1932, produced nearly 400,000 units for one
year and quickly occupied the world market for the full
specification, good structure, reliable performance, easy
maintenance, low exhaust and long period maintenance. Perkins
service network is in more than 180 countries and regions.
Product characteristics:
1. Our cooperate with famous diesel engine -Powered by famous
Perkins engines.
2. Equipped with famous Brushless alternator - Optional Stamford,
Leroy Somer, Marathon, Meccalte.
3. Equipped with 50°C radiator with fan, enough engine cooling
system guarantee long time working
4. Equipped with advanced generator set control system, ATS system,
remote control system, parallel operation system, optional control
model, Deep sea, Smartgen, ComAp,
5. Generator set use High-quality steel are thickness canopy -- 2MM
to 6MM
6. Generator equipped with 24V DC battery with charger, battery
connects wire.
7. New design of turn-back type for air inflow & air outlet which
can reduce the noise and improve engine efficiency.
8. Beautiful & practicably design, Bottom hole for forklift, Water
outlet & oil outlet for easy maintenance
Generator Specifications:
| GENERAL ENGINE DATA | |
| Engine manufacture | Perkins Engines Company Limited |
| Engine brand | Perkins |
| Engine model | 4006-23TAG2A |
| Engine speed (rpm) | 1500 |
| Baseload power | Prime power | Standby power |
| Gross engine power (kWb) | 531 | 658 | 721 |
| Typical Genset electrical output 0.8pf 25ºC (100 kPa) (KW) | 476 | 597 | 656 |
| Cylinders | 6-cylinder, vertical in line |
| Cycle | 4 stroke |
| Induction system | Turbocharged |
| Combustion system | Direct injection |
| Compression ratio | 13.6:1 |
| Bore * Stroke (mm) | 160 * 190 |
| Cubic capacity (Litre) | 22.921 |
|
| FUEL SYSTEM | |
| Injection system | Direct |
| Governor type | electronic |
| Fuel Consumption (litre/hour) | |
| Standby | 178 |
| Prime | 163 |
| Baseload | 133 |
| 75% output power | 124 |
| 50% output power | 84 |
|
| COOLING SYSTEM | |
| Max. top temperature(standby) (°C) | 98 |
| Thermostat operating range (°C) | 71-85 |
| Shutdown switch setting (°C) | 101 |
|
| LUBRICATION SYSTEM | |
| Maximum sump capacity (liter) | 113.4 |
| Minimum sump capacity (liter) | 90.7 |
| Oil pressure at rated speed (kPa) | 300 |
| Oil pressure Minimum @80°C (kPa) | 240 |
|
| INDUCTION SYSTEM | |
| Maximum air intake restriction of engine (kPa) | |
| Clean filter | 1.25 |
| Dirty filter | 3.7 |
| Combustion air flow(standby/prime power) (m3/min) | 72 / 65 |
|
| EXHAUST SYSTEM | |
| Back pressure for total system (kPa) | 6 |
| Exhaust gas temp. after turbo(standby/prime power)(°C) | 430 |
| Exhaust gas flow (standby/prime power) (m3/min | 180 |
|
| ELECTRICAL SYSTEM | |
| Alternator voltage (volts) | 24 |
| Alternator output (amps) | 55 |
| Stater motor type (volts) | 24 |
| Starter motor power (kw) | 7.5 |
Detection and protection function
Over / under speed, Low Oil Pressure, High Water Temperature, under
Battery Volt, Low water level,Three failed to start alarm
Over / under voltage,Over current,Over / under frequency, Over
Power, Short circuit
Optional features
RS485 (DSE7320)RS485(DSE7320)
Fuel level display and low-alarm
Water level low-alarm
Water Pre- heating in low temperature
ATS
Automatic parallel (DSE6120 / DSE7320)
Other self-definition functions
