500kw Portable Diesel Generator Volvo Engine Generation 625kva
Volvo Penta TWD1643GE
Volvo penta TWD1643GE generator set
are environmentally friendly,and the emission situation achieve
European Union 2 or 3 and EPA environmental standards,which selects
electronic injection diesel engines prestigious from Sweden
Volvo group production.Volvo company is founded in 1927,that
shining brand is closely associated with its three core
values-quality,safety,environmental protection.Volvo diesel
generator set features:cold starting,strong loading
capability,small volume,low fuel consumption,long service life.
Engine Specifications:
| Model | A688 |
| Power | 625KVA/500KW |
| Frequency | 50HZ |
| Voltage | 400/230v(voltage can be customized) |
| Optional Type | Open/soundproof/trailer |
| Size of Open type | 3300*1400*1950mm |
| Weight of Open type | 3500kg |
| With Diesel Engine |
| Brand&model | Volvo TWD1643GE |
| Cylinders | 6 in line arrangement |
| Bore*Stroke | 144*165mm |
| Displacement | 16.12L |
| Fuel Consumption at 100% Load | 199g/kw.h |
| Speed Governor | Electronic |
| With Alternator |
| Optional Brands | Stamford/Leroy Somer/Mecc Alte/Marathon |
| Exciter type | Single bearing,brushless,Self-excited |
| Power factor | 0.8 |
| Voltage adjust range | ≥5% |
| Insulation Grade | H |
| Protection Grade | IP23 |
| With Controller |
| Optional brands | Deepsea/ComAp/Smartgen |
Product Details
The TWD1643GE is a powerful, reliable and economical Generating Set
Diesel Engine built on the dependable in-line six design.
Durability & low noise
Designed for easiest, fastest and most economical installation.
Well-balanced to produce smooth and vibration-free operation with
low noise level. To maintain a controlled working temperature in
cylinders and combustion chambers, the engine is equipped with
piston cooling. The engine is also fitted with replaceable cylinder
liners and valve seats/guides to ensure maximum durability and
service life of the engine.
Low exhaust emission
The state of the art, high-tech injection and charging system with
low internal losses contributes to excellent combustion and low
fuel consumption. The TWD1643GE is certified for EPA Tier 2. An
additional feature is that TWD1643GE fulfils EU Stage 2 exhaust
emission levels.
Easy service & maintenance
Easily accessible service and maintenance points contribute to the
ease of service of the engine.
1. What is your warranty period?
A: Our warranty period is 1 year or 1000 running hours, whichever
comes first (Except the damageable spare parts of genset caused by
incorrect man-made operation).
2. Does your generator have global warranty?
A: Yes. Gensets powered by USA famous engine, with UK famous
engine, Volvo, Iveco have the global warranty service. And the
alternators Stamford, Leroysomer, Meccalte, Marathon also have the
global warranty service.
3. What is your payment terms?
A: T/T 30% advance payment, the balance 70% shall be paid before
shipment, L/C at sight.
4. Can the generators be customized?
A: Yes. Our generators can be customized depending on customer's
detailed requirements. We can supply generators for rental
business, home use, industrial projects, army projects, power
station, etc. The generators we supply is suitable for indoor and
outdoor use, lower and high temperature environment.
5. Can you use our logo?
A: Yes. For mass orders, we can use customer's logo instead of
ours.
