50HZ Marine Perkins Diesel Generator Set 1250kva Marine Generator 4008-30TAG3

Product Categories

Xiamen Ai Power Technology Co., Ltd.

Contact Now

50HZ Marine Perkins Diesel Generator Set 1250kva Marine Generator 4008-30TAG3

Ask Lasest Price
Brand Name :	Ai Power 900KW 1125KVA Perkins Diesel Power Prise
Model Number :	AP1125
Certification :	CE, ISO9001
Price :	USD 100000 to 110000 Per Unit Negotiable
Payment Terms :	Western Union, L/C, T/T, MoneyGram
Supply Ability :	300 Units Per Month
Delivery Time :	30 Days

Add to Cart

Product Details
Company Profile

50HZ Marine Perkins Diesel Generator Set 1250kva Marine Generator 4008-30TAG3

50HZ 1500RPM Three Phase 1000kw 1250kva Perkins Diesel Motors Electric Backup Generator

4000 Series 4008-30TAG3 ElectropaK 1055 kWm @ 1500 rpm net standby power

The Perkins® 4000 Series is a family of 6, 8, 12 and 16 cylinder diesel engines, designed to address today’s uncompromising demands within the power generation industry with particular aim at the standby market sector.

Developed from a proven engine range that offers superior performance and reliability. The 4008-30TAG3 is a turbocharged and air-to-air charge cooled, 8 cylinder diesel engine offered in an engine only confirgration. Its premium features and design provide economic and durable operation as well as an exceptional power to weight ratio, excellent load acceptance and improved gaseous emissions, plus the overall performance and reliability characteristics essential to the power generation market.

Perkins Engine Specs

Number of cylinders	8 vertical in-line
Bore and stroke	160 x 190 mm
Displacement	30.561 litres
Aspiration	Turbocharged and air to air charge cooled
Cycle	4 stroke
Combustion system	Direct injection
Compression ratio	13.6:1
Rotation	Anti-clockwise, viewed from flywheel end
Total lubricating capacity	153 litres
Cooling system	Water-cooled
Total coolant capacity	48 litres

Alternator Specs

Alternator	Famous brand	Stamford ,Leroy Somer,Mecc Alte,Marathon
	China Brand	Ai Power, Kaijieli
Power Range	5kw to 3000kw
Insulation class	H
Phase/Wire	3 phase/ 4 wire	1 phase/ 2 wire

Control panel:900 kw diesel generator

Brand

Deepsea/ComAp/Smartgen

The control module gives digital readouts of:

Generator voltage;

Output frequency;

Engine speed;

Battery voltage;

Engine hours run.

The control module has indicators for failure

information:

Overspeed/underspeed,

Emergency stop

Low oil pressure;

High water temperature

Failure to start

Battery charger failure

Automatic shutdown occurs under:

Low engine oil pressure;

High engine water temperature;

Overspeed/underspeed;

Failure to start after three attempts.

Optional-addtional parts :900 kw diesel generator price

Engine	Fuel System	Cooling system	Exhaust system
Coolant Heater Lube oil heater Electronic governor Engine oil temperature	External Tank Water Separator	50-60 Radiator, Remote radiator Cooling tower	Heavy Duty air filter Silencer Enclosures
Alternator	Control System	Others	Voltage Connections
Anti Condensation Heater Permanent Magnet Generator-PMG Drop CT-for paralleling	Remote Control Panel Auto Transfer Switch ATS-Control Panel Paralleling System Electricity Output Cabinet	Rainproof Type Soundproof Type Containerized Type Trailer Type Spare Parts	480/277V 440/254V 416/240V 400/230V 380/220V 240/139V 220/12 V 208/120V
High Voltage of 6.3kv, 6.6kv, 10.5kv, 13.8kv etc are available

About US

AI Power Factory Introduction

High quality, reliable and complete power unit

Compact design

Easy start and maintenance possibility

Every generating set is subject to a comprehensive test program which includes full load testing, checking and provision of all control and safety shut down functions testing

Fully engineered with a wide range of options and accessories: Canopy, sound proof canopy and on - road trailer
