Low Noise Silent Cummins 22kw 24kw Home Use Soundproof Type Diesel
Generator
Are you looking for silent diesel generator, Our company mainly
produce international famous brand Cummins, Perkins, Doosan, Deutz,
Mitsubishi, MTU engine powered generators from 10kva to 3000kva for
more than 15 years, the alternator we adopt Leroysomer, Stamford,
Meccalte to guarantee the whole generator set good quality. All of
our diesel generators have CE certificate, we also supply good
design of silent canopy, ATS, Synchronization system etc.
Product Description
| Genset | Power Capacity (kw/kva) | 20/25 |
|
| Rated Voltage (V) | 400/230 |
| Rated Current (A) | 36 |
| Rated Frequency (Hz) | 50/60 |
| Rated Speed (rpm) | 1500 |
| Power Factor / Phase | Cos 0.8 Lagging, 3 phase |
| Cooling System | Closed cycle water-cooled with fan,water tank |
| Overall Dimension (L×W×H) (mm) | 2000x850x1300 |
| Gross Weight (kg) | 1180 |
Diesel
Engine | Engine Model | 4B3.9-G2 |
| Prime Power (kw) | 27/33.75 |
| Engine Structure | 4 Cylinder,Vertical,Inline,4 stroke |
|
| Bore×Stroke (mm) | 102x120 |
| Displacement (L) | 3.9 |
| Compression Ratio | 16.5:1 |
| Lube Capacity (L) | 11 |
| Fuel System | PT type fuel injection pump |
| Fuel Consumption (g/kw.h) | 229 |
| Lube Consumption (g/kw.h) | 0.5% |
| Rotating Speed (rpm) | 1500 |
| Speed Governing | Electronic speed governor |
| Starting Method | By 24V batteries |
AI power USA series generator set adopts USA engine as the power
source. it’s a global power leader who is devoted to the engine
R&D and manufacturer since 1919 in Columbus, now it has become
the largest engine manufacturer in the world providing more than
160 countries sales and aftersales service. Ai Power AC series
generator has adopted DCEC and CCEC engine include 4B, 6B, 6C, 6L,
NTA, MTA, KTA series etc.
The generator set standard configuration:
1. Assembled by USA famous diesel engine and high quality branded
alternator.
2. Radiator and fan with safety guard, or heat exchanger.
3. Heavy duty steel base frame with great capacity fuel tank for
options.
4. Vibration damping supports between engine/alternator and base
frame.
5. Heavy duty industrial type exhaust silencer with flexible
bellow.
6. High capacity sealed lead acid battery with battery cable.
7. Intelligent control panel, Deepsea or Comap brand for options.
Product Details
Packing and Delivery
1. What is your warranty period?
A: It’s 1 year or 1000 running hours whichever comes first. But
based on some special project, we can extend our warranty period.
2. Can you accept OEM?
A. Yes, we can accept OEM.
3. What’s your payment term?
A: We can accept T/T 30% in advance and the balance 70% shall be
paid before shipment or LC at sight.
4.What’s your delivery time?
A:Our normal delivery time is 2 to 4 weeks. But if your order is
some special engine and alternator, the delivery time will be
longer.
