    100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator

    Ask Lasest Price
    Brand Name : Ai Power
    Model Number : AC110-P
    Certification : CE, ISO
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 200 units per month
    Delivery Time : 25 to 35 days
    • Product Details
    • Company Profile

    100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator

    Mobile Diesel Generator 100kva With Cummins Portable Generator Gensets With Wheels

    Cummins Engine


    Cummins is the world’s largest independent engine manufacturer, with a range of diesel and gas engines extending from 37 to 3132 kW (49 to 4200 hp), from the smallest (2.8 litres) to the largest (95 litres). With global manufacturing and support, Cummins serves customers around the world offering power solutions for the following market sectors:

    • Agriculture
    • Automotive: Coach, Bus and Truck
    • Construction & Industrial
    • Defence
    • Mining
    • Marine: Commercial, Recreational & Military applications
    • Oil and Gas
    • Rail

    All Cummins Engines are built with the strength and reliability that have made Cummins a leader for many decades. All engines are fully backed by Cummins global parts and service network. So you can specify Cummins power with complete confidence.


    Engine Specifications:


    Engine Model

    6BTA5.9-G2

    Number of Cylinders

    6 cylinders in line

    Cycle

    4 stroke

    Aspiration

    Turbocharged and after water cooled

    Bore×Stroke

    102mm x120mm

    Displacement

    5.9L

    Compression ratio

    17.5:1

    Prime Power/Speed

    106KW / 1500rpm

    Standby Power/Speed

    116KW / 1500rpm

    Speed Governor

    Electrical

    Cooling System

    Forced water cooling cycle

    Steady speed droop

    ≤1%

    Total lubrication system capacity

    16.4L

    Coolant capacity (engine only)

    9.1L

    Fuel Consumption at 100% Load

    211g/kw.h

    Starter Motor

    DC24V,

    Alternator

    DC24V


    Alternator Spec

    Alternator Model

    UCI274D

    Prime power

    96KW

    Frequency/speed

    50HZ/1500rpm

    Exciter type

    Single bearing, Brushless, Self-excited

    Power factor

    0.8

    Voltage adjust range

    ≥5%

    Voltage regulation NL-FL

    ≤±1%

    Insulation Grade

    H

    Protection Grade

    IP23

    Phase

    Three phases


    Control Panel

    Model

    MRS10/DSE6020/HGM6110N...

    The control module gives digital readouts of:

    Generator voltage;

    Output frequency;

    Engine speed;

    Battery voltage;

    Engine hours run.

    The control module has indicators for failure

    information:

    Overspeed/underspeed,

    Emergency stop

    Low oil pressure;

    High water temperature

    Failure to start

    Battery charger failure

    Automatic shutdown occurs under:

    Low engine oil pressure;

    High engine water temperature;

    Overspeed/underspeed;

    Failure to start after three attempts.


    100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator


    Factory Overviews
    100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator100 Kva 106KW Water Cooled Portable Generator Cummins 150kw Diesel Generator

    FAQ

    1.Are you a factory or trading company?

    A: We are a factory.

    2.What is the material of your products?

    A: Iron, Steel, plastic, etc.

    3.How about quality control in your factory?

    A: AI people are always paying great attentions to quality controlling from the beginning to the end.

    4.How about your guarantee?

    A: Our warranty period is 1 year or 1000 running hours, whichever comes first.
